What's in the box
Box content
- MiniBrute 2S unit
- Power cord
- 8 patch cables
- a “Cook Book” jam-packed full of superb sonic recipes for you to try out, put together by some of the most illustrious synth-chefs around.
Instrument dimensions
- Size : 19 x 11 x 2.2 inches (484 x 277 x 56mm)
- Weight : 7.7 lbs. (3.5 Kg)
Main Features
Analog Synthesizer
2 Analog VCO’s:
- VCO1 : Saw + UltraSaw, Square +Pulse width, Triangle + Metalizer. (Waveform mixing)
- VCO2 : Sine, Saw, Square waveforms (three tuning ranges).
VCO 2>1 Hard Sync, VCO1 linear and exponential FM
White Noise Generator
External Audio In
Steiner Parker filter (12dB per octave): Low Pass, High Pass, Band Pass, Notch modes.
2 LFO’s with Sync: Sine, Tri, Saw, Square, Random, Slew Random
1 ADSR envelope
1 AD envelope
- Trig, Gate modes
- One shot or Loop
- Attack and Decay times CV controllable
48-point CV and Gate patchbay
- Inputs and Outputs for the voice and sequencer
- Utility modules: inverter, attenuators, VCA
16 velocity and pressure sensitive pads
16 encoders
64 sequence memories
- Sequence Pitch, Gate, Velocity and Pressure on up to 64 steps
- Alternatively, sequence modulations such as Gates, LFOs, AD Envelopes, ...
- Real-time or step recording modes
- Arpeggiator/Looper
