Create right away!
Ultra-affordable, surprisingly powerful, and small enough to fit in your pocket, AudioBox GO™ gives you all the connections you need to record on the move or in your home studio. Whether you’re recording a guitar riff at rehearsal or a full-length solo album in your bedroom, you’ll have all the tools you need to create like a pro, right from the start. Compatible with both computers and mobile devices, the AudioBox GO is perfect for anyone who wants to get started recording fast.
Studio One® Prime and the Studio Magic software bundle for Mac® and Windows® are also included, so your new recording studio will be up and running right out of the box. With AudioBox GO , you can record wherever sound takes you and make recording the adventure that it should be.
Small but Beautiful
True to its name, the AudioBox GO™ is so powerful and loaded with features, you’ll want to take it with you everywhere — it's small enough to toss into your guitar case or your laptop bag. AudioBox GO works great with Android and Apple mobile devices — but also with both laptop and desktop computers, making it an ideal interface for small home studios. It's USB class-compliant, so there are no special drivers or applications for you to download and install. And because it’s bus-powered, there’s no power supply to fuss around with.
Technical Specifications
| Microphone Preamp | |
|---|---|
| Type | XLR female, balanced (via Combo connector Input 1) |
| Frequency Response (±3.0 dB) | 20 Hz to 20 kHz |
| Input Impedance (Balanced) | 1.4kΩ |
| THD+N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain) | < 0.004% |
| Gain Control Range (± 1 dB) | 50 dB (0 dB to +50 dB) |
| Max Input Level (Unity Gain, 1 kHz @ 0.5% THD+N) | +10 dBu (± 0.5 dBu, min gain) |
| Phantom Power (±2 VDC) | +48 VDC (±2 VDC) |
| Line Input | |
|---|---|
| Type | ¼" TS female, balanced (via Combo connector Input 1) |
| Input Impedance | 750 kΩ |
| Max Input Level | +19 dB |
| Gain Control Range | 50 dB (-20 dB to +30 dB) |
| Instrument Input | |
|---|---|
| Type | ¼" TS female, unbalanced (Input 2) |
| Input Impedance | 750 kΩ |
| Max Input Level | +13 dB |
| Gain Control Range | 50 dB (0 dB to +50 dB) |
| Line Output | |
|---|---|
| Type | ¼" TRS female, impedance balanced |
| Frequency Response | 20 Hz to 20 kHz, +/-0.2 dB |
| Output Impedance | 51Ω |
| THD+N (1 kHz, 20 kHz BW, A-wtd) | <0.007% |
| Headphone Output | |
|---|---|
| Type | ¼" TRS active stereo |
| Maximum Output | 30 mW/ch. @ 60Ω Load |
| Frequency Response (±1.0 dB) | 20 Hz - 20 kHz, +- 0.5 dB |
| THD+N (1 kHz, max gain, 20 kHz BW, A-wtd) | <0.08% |
| S/N Ratio (1 kHz, max gain, 20 kHz BW, A-wtd) | 90 dB |
| Power | |
|---|---|
| Type | Bus Powered |
| Digital Audio | |
|---|---|
| Connection Type | USB 2.0 over USB-C® compatible connection |
| ADC Dynamic Range (A-wtd, 48 kHz Sample Rate) | 90 dB |
| DAC Dynamic Range (A-wtd, 48 kHz Sample Rate) | 102 dB |
| Bit Depth | 24 |
| Reference Level for 0 dBFS | +10 dBu |
| Supported Sample Rates (kHz) | 44.1, 48, 88.2, 96 |
| Physical | |
|---|---|
| Height | 1.73” (44 mm) |
| Depth | 3.3" (84 mm) |
| Width | 4.25" (108 mm) |
| Weight | 0.51 lb (0.24 kg) |
